| System |
| CPU |
|
Intel&ereg uFC-LGA 775 socket Supports Quad-core Core 2 Extreme / Core 2 Duo / Pentium® D PentiumR 4 / CeleronR D with 65nm process technologyrpo |
| FSB |
|
1066/800/533 MHz |
| BIOS |
|
Award 16 Mb Flash ROM BIOS |
| System Chipset |
|
Intel® 82Q965 GMCH / ICH8DO |
| I/O Chip |
|
Winbond W83627DHG-A |
| System Memory |
|
Four 240-pin DIMM sockets support up to
8 GB Dual Channel DDR2 800/667/533 SDRAM |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring temperatures, voltages, and cooling fan status. Auto throttling control when CPU overheats |
| Expansion |
|
One PCI Express X16, five PCI slots
(PCI Rev. 2.2 compliant), 2 ISA |
| I/O |
| MIO |
|
1 x UltraDMA 133/100/66/33, 8 x SATA,1 x FDD,
1 x LPT, 4 x RS-232, 1x K/B,1 x Mouse |
| USB |
|
10 x USB 2.0 port |
| e-SATA |
|
1 x e-SATA |
| IEEE-1394A |
|
1 x 1394 (optional)tm |
| Display |
| Chipset |
|
Intel® 82Q965 GMCH integrated Graphics
Media Accelerator 3000 |
| Display Memory |
|
Intel® DVMT 4.0 supports 256 MB video memory |
| Max. 3D Resolution |
|
2048 x 1536 @ 32 bpp (75Hz) |
| VGA/LCD Interface |
|
PCI-E X16 VGA interface |
| LVDS |
|
Through ADD2 HDMI Card
(Customized BIOS required) |
| DVI |
|
Through ADD2 LVDS Card
(Customized BIOS required) |
| TV-out |
|
Through ADD2 DVI Card
(Customized BIOS required) |
| DTV-out |
|
Through ADD2 TV-out Card
(Customized BIOS required) |
| Audio |
| Chipset |
|
Intel® ICH8DO |
| AC97 Codec |
|
ADIR AD1988 7.1-channel High Definition
Audio CODEC |
| Audio Interface |
|
Mic in, Line in, CD Audio in, Line out,
6CH (6 jacks), S/PDIF |
| Ethernet |
| LAN 1 |
|
Intel® 82566DM Gigabit LAN |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
* 1 x PS/2 Keyboard
* 1 x PS/2 Mouse
* 1 x Parallel port
* 1 x External SATA
* 1 x VGA port
* 1 x IEEE1394a connector (optional)
* 1 x RJ45 port
* 4 x USB 2.0/1.1
* 7.1 CH Audio I/O (6 jacks) |
| Internal I/O Connector |
| Internal I/O Connector |
|
* 3 x USB connectors support
additional 6 USB ports
* 1 x 24-pin ATX Power connector
* 1 x 4-pin ATX 12V Power connector
* 1 x Floppy disk drive connector
* 1 x IDE connector for two devices
* 4 x COM connector
* 1 x CD audio in connector
* 1 x TPM connector
* 7 x SATA connectors
* 1 x Front panel audio connector
* 1 x S/PDIF Out Header
* 1 x System panel connector
* 1 x CPU Fan connector
* 2 x Chassis Fan connector
* 1 x IEEE1394a connector (optional) |
| Mechanical & Environmental |
| Power Type |
|
ATX |
| Operating Temperature |
|
0~60°C (32~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
12" x 9.6" (304.8 mm x 243.84 mm) |
| Weight |
|
1.32 lbs (0.6 Kg) |
