| System |
| CPU |
|
Onboard Intel® Celeron® M 600MHz w/512K L2 Cache |
| FSB |
|
400MHz |
| BIOS |
|
Award 4 Mb Flash BIOS |
| System Chipset |
|
Intel® 82852GM GMCH/82801DB ICH4 |
| I/O Chip |
|
Winbond W83627EHG-A |
| System Memory |
|
One 184-pin DIMM socket supports up to
1 GB DDR 200/266 SDRAM |
| SSD |
|
One CompactFlash Type I/II socket |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring CPU temperature, voltage, and cooling
fan status. Auto throttling control when
CPU overheats |
| Expansion |
|
One PCI slot (PCI Rev. 2.2 compliant)
supports 3 PCI master |
| S3 |
|
S3 Support |
| SmartFan Control |
|
Speed Cruise Mode |
| I/O |
| MIO |
|
1 x EIDE (Ultra DMA 100), 4 x RS-232 |
| USB |
|
6 x USB 2.0 |
| DIO |
|
16-bit General Purpose I/O for DI and DO |
| Extra SATA Chips |
|
Silicon Image Sil 3512 supports 2 SATA
with 150 MB/s transfer rate |
| Display |
| Chipset |
|
Intel® 82852GM GMCH integrated Extreme |
| Display Memory |
|
Intel® DVMT 2.1 supports up to 64 MB video memory |
| Resolution |
|
CRT mode: 1600 x 1200 @ 32 bpp (85 Hz)
LCD/Simultaneous mode:
1600 x 1200 @ 32 bpp (85 Hz) |
| Dual Display |
|
CRT + LVDS, or CRT + DVI |
| LVDS |
|
Intel® 852GM supports Single channel 18 /
Dual-channel 36-bit LVDS |
| DVI |
|
Chrontel CH7301 DVI transmitter up to
135M pixels/second |
| Audio |
| Chipset |
|
Intel® 82801DB ICH4 |
| Audio Code |
|
Realtek ALC655 supports 5.1 CH Audio ( 3 jacks ) |
| Audio Interface |
|
Mic in, Line in, Line out |
| Audio Amplifer |
|
TPA3005D2 Stereo 5 Watt per channel |
| Ethernet |
| LAN1 |
|
Realtek RTL8110SC 1000Base-T Gigabit
Ethernet Controller |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
* 1 x PS/2 Keyboard
* 1 x PS/2 Mouse
* 2 x RS-232
* 1 x VGA port
* 1 x DVI port 4 x USB 2.0/1.1
* 1 x RJ45 Port
* 5.1 CH Audio I/O (3 jacks) |
| Internal I/O Connector |
| Internal I/O Connector |
|
* 1 x USB connectors support
2 USB ports
* 1 x 20-pin ATX Power connector
* 1 x IDE 40-pin connector for two devices
* 2 x COM port header
* 2 x SATA connectors
* 1 x Front panel audio connector
* 1 x Audio amplifier connector |
| Mechanical & Environmental |
| Power Type |
|
ATX |
| Operating Temperature |
|
0°~60°C (32°~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
6.69" x 6.69" (170 mm x 170 mm) |
| Weight |
|
0.88 lbs (0.4 Kg) |
Specifications
