| System |
| CPU |
|
Supports Intel® uFC-PGA 478 Core Duo /
Core Solo / Core 2 Duo with 65nm process technology |
| FSB |
|
533/667 MHz |
| BIOS |
|
Award 4 Mb Flash BIOS |
| System Chipset |
|
Intel® 82945GM GMCH/82801GBM ICH7-M DH |
| I/O Chip |
|
Winbond W83627DHG-A |
| System Memory |
|
Two 240-pin DIMM sockets support up to 4 GB
Dual Channel DDR2 533/667 SDRAM |
| SSD |
|
One CompactFlash Type I/II socket |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring CPU temperature, voltage, and cooling fan status. Auto throttling control when
CPU overheats |
| Expansion |
|
One PCI slot (PCI Rev. 2.2 compliant)
supports 3 PCI master |
| S3 |
|
S3 Support |
| SmartFan Control |
|
Speed Cruise Mode |
| I/O |
| I/O |
|
MIO 1 x EIDE (Ultra DMA 100), 2 x SATA,
4 x RS-232 , 1 x K/B, 1 x Mouse |
| USB |
|
8 x USB 2.0 |
| DIO |
|
16-bit General Purpose I/O for DI and DO |
| Display |
| Chipset |
|
Intel® 82945GM GMCH integrated Graphics
Media Accelerator 950 |
| Display Memory |
|
Intel® DVMT 3.0 supports 224 MB video memory |
| Resolution |
|
2048 x 1536 @ 32 bpp (85 Hz) |
| Dual Display |
|
CRT + LVDS, or CRT + DVI-D |
| VGA/LCD Interface |
|
D-SUB +DVI-Dtm |
| LVDS |
|
Intel® 945GM supports Single channel 18/24-bit or Dual-channel 36-bit LVDS |
| DVI |
|
Chrontel CH7307C DVI transmitter up to
165M pixels/second |
| Audio |
| Chipset |
|
Intel® 82801GBM ICH7-M DHx-xbitm |
| Audio Code |
|
ADI 1882 5.1-CH HD Audio Codec |
| Audio Interface |
|
Mic in, Line in, (CD Audio in), Line out |
| Audio Amplifer |
|
TPA3005D2 Stereo 5 Watt per channel |
| Ethernet |
| LAN1 |
|
Realtek RTL8110B PCI-E 1000Base-T
Gigabit Ethernet Controller |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
*1 x PS/2 Keyboard
*1 x PS/2 Mouse
*2 x RS-232
*1 x VGA port
*1 x DVI port
*4 x USB 2.0/1.1
*1 x RJ45 Port
*5.1 CH Audio I/O (3 jacks) |
| Internal I/O Connector |
| Interanl I/O Connector |
|
* 2 x USB connectors support 4 USB ports
* 1 x 20-pin ATX Power connector
* 1 x IDE 40-pin connector for two devices
* 2 x COM port header
* 2 x SATA connectors
* 1 x Front panel audio connector
* 1 x Audio amplifier connector |
| Power Type |
|
ATX |
| Mechanical & Environmental |
| Operating Temperature |
|
0~60°C (32~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
6.69" x 6.69" (170 mm x 170 mm) |
| Weight |
|
0.88 lbs (0.4 Kg) |
