| System |
| CPU |
|
Supports Intel® uFC-PGA 478 / uFC-BGA 479 Pentium® M / Celeron® M with 0.13 u and 90nm process technology |
| FSB |
|
400/533 MHz |
| BIOS |
|
Award 4 Mb Flash BIOS |
| System Chipset |
|
Intel® 82915GME GMCH/82801FBM ICH6-M |
| I/O Chip |
|
Winbond W83627EHG-A |
| System Memory |
|
Two 240-pin DIMM socket supports up to 2 GB DDR2 400/533 SDRAM |
| SSD |
|
One CompactFlash Type I/II socket |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring CPU temperature and cooling fan status. Auto throttling control when CPU overheats |
| Expansion |
|
One PCI slot (PCI Rev. 2.2 compliant) supports
3 PCI master |
| S3 |
|
S3 Support |
| SmartFan Control |
|
Speed Cruise Mode |
| I/O |
| MIO |
|
1 x EIDE (UDMA 100), 2 x SATA, 4 x RS-232,
1 x K/B, 1 x Mouse |
| IrDA |
|
115k bps, IrDA 1.0 compliant |
| USB |
|
8 x USB 2.0 |
| DIO |
|
16-bit General Purpose I/O for DI and DO |
| Display |
| Chipset |
|
Intel® 82915GME GMCH integrated Graphics
Media Accelerator 900 |
| Display Memory |
|
Intel® DVMT 3.0 supports up to 128 MB video memory |
| Resolution |
|
2048 x 1536 @ 32 bpp (85 Hz) |
| Dual Display |
|
CRT + LVDS, or CRT + DVI-D |
| LVDS |
|
Intel® 915GME supports Single channel
18-bit / Dual-channel 36-bit LVDS |
| DVI |
|
Chrontel CH7307C DVI transmitter up to
165M pixels/second |
| Audio |
| Chipset |
|
Intel® 82801FBM ICH6-M |
| Audio Code |
|
Realtek ALC655 supports 5.1 CH Audio |
| Audio Interface |
|
Mic in, Line in,Line out |
| Audio Amplifer |
|
TPA3005D2 Stereo 5 Watt per channel |
| Ethernet |
| LAN1 |
|
Realtek RTL8110SC PCI-E 1000Base-T Gigabit Ethernet Controller |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
* 1 x PS/2 Keyboard
* 1 x PS/2 Mouse
* 2 x RS-232
* 1 x VGA port
* 1 x DVI port
* 4 x USB 2.0/1.1
* 1 x RJ45 Port
* 5.1 CH Audio I/O (3 jacks) |
| Internal I/O Connector |
| Internal I/O Connector |
|
* 2 x USB connectors support 4 USB ports
* 1 x 20-pin ATX Power connector
* 1 x IDE 40-pin connector for two devices
* 2 x COM port header
* 2 x SATA connectors
* 1 x Front panel audio connector |
| Mechanical & Environmental |
| Power Type |
|
ATX |
| Operating Temperature |
|
0~60°C (32~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
6.69" x 6.69" (170 mm x 170 mm) |
| Weight |
|
0.88 lbs (0.4 Kg) |
